High Contrast GOB Indoor Fixed Led Display Screen Modules ODM

Product Details

Place of Origin: China

Brand Name: JC

Certification: CE FCC

Payment & Shipping Terms

Minimum Order Quantity: Negotiable

Price: Negotiable

Packaging Details: wooden case，flight case

Delivery Time: 5-7 working days

Payment Terms: T/T, Western Union, L/C

Supply Ability: 4300 sqm month

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                ODM indoor fixed led display, GOB indoor fixed led display, ODM indoor led screen


Model:	GOB LED Module	Screen Weight:	40kg/㎡
Density:	640,000 Pixel/m2	Power Supply:	Meanwell
Cabinet Quality:	Iron	Specification:	Video Wall
Refresh Rate:	≥1920Hz	Cabinet Dimension:	640*480mm/customized
Scan Method:	1/16 S	Pixel Configuration:	1R1G1B/SMD3528 White Lamp
Display Function:	Video Walls,poster Advertising Show	Materials:	Die-cast Aluminum Cabinets
Contrast:	1000:1	Material:	Metal Case + Toughened Glass Panel
Control Distance:	Cable100m，Multimode500m，Single Mode 2km

Model:	GOB LED Module
Screen Weight:	40kg/㎡
Density:	640,000 Pixel/m2
Power Supply:	Meanwell
Cabinet Quality:	Iron
Specification:	Video Wall
Refresh Rate:	≥1920Hz
Cabinet Dimension:	640*480mm/customized
Scan Method:	1/16 S
Pixel Configuration:	1R1G1B/SMD3528 White Lamp
Display Function:	Video Walls,poster Advertising Show
Materials:	Die-cast Aluminum Cabinets
Contrast:	1000:1
Material:	Metal Case + Toughened Glass Panel
Control Distance:	Cable100m，Multimode500m，Single Mode 2km

Product Description

Indoor fixed installation

JCFixed-indoor Advantages

Less weight with 5.5kg per cabinet

Front and back maintenance

Intellgent modules for any area change

Multi pixel pitch with one cabinet

High contrast and unifmority

Offline Message

Specifications

JCfix-in	JCfix-in-1.53	JCfix-in-1.86	JCfix-in-2	JCfix-in-2.5	JCfix-in-3
Pixel pitch(mm)	1.53	1.86	2	2.5	3
Pixel Density(dot/m2)	427716	289247	250000	160000	111111
LED Type	SMD1212	SMD1515	SMD1515	SMD2020	SMD2020
Module Size(W x H x D)mm	320x160mm	320x160mm	320x160mm	320x160mm	192x192mm
Module resolution(W x H)	209x105	172x86	160x80	128x64	64x64
Module Weight(Kg)	0.6kg	0.6kg	0.6kg	0.6kg	0.6kg
Power Consumption per Module(w)	35	33	30	29	29
Diver Mode(Scan)	1/52	1/43	1/40	1/32	1/32
Brightness(cd/m2)	600~800nit	900nit	900nit	900nit	1000nit
Grey Scale	16384	16384	16384	16384	16384
Refresh Rate(Hz)	≥2880Hz	≥2880Hz	≥2880Hz	≥2880Hz	≥2880Hz
Cabinet Size(W x H x D)mm	640x480x63mm	640x480x63mm	640x480x63mm	640x480x63mm	576x576x63mm
Cabinet Weight(Kg/Cabinet)	5.6Kg	5.6Kg	5.6Kg	5.6Kg	5.6Kg
Max Power Consumption(W/m2)	550	565	550	520	520
Average Power Consumption(W/m2)	250	200	180	170	170
View Angle(H°/V°)	160/160	160/160	160/160	160/160	160/160
Mini View Distance(m)	1	1	2	2	3
Operating Use Temperature(℃)	-10℃~40℃
Storage Use Temperature(℃)	-20℃~50℃
Input Voltage(V)	100~240V
Input Power Frequency(Hz)	50Hz~60Hz
Failure Rate	＜1/100,1000
Signal Input Format	SDI, RGBHV,YUV,YC,Composite,HDMI,DVI,SD/HD-SDI etc.
Life Time(hrs)	100,000
IP Level(front/rear)	IP30 /IP30
